WELCH Duoseal, Mounted Pump, 115V 60Hz 1Ph, 23 CFM
$9,913.80
In stock
Overview
SKU1374B-01
WELCH Duoseal, Mounted Pump, 115V 60Hz 1Ph, 23 CFM
Overview
WELCH Duoseal, Mounted Pump, 115V 60Hz 1Ph, 23 CFM
Overview
Welch Belt-drive vacuum pumps are known for their ruggedness world-wide in the most demanding applications
- Low pump rpm to reduce frictional wear while minimizing reservoir temperature to lessen chemical activity
- High oil feed to pump models leads to cleanest oil lubricating the internal pump module
- Large oil reservoirs dilute contaminants ingested into the pump
| Product Type | Vacuum Pump |
|---|---|
| Flow Rate | 23 CFM (650 l/min) |
| Maximum Vacuum | 0.001 torr |
| Oil Capacity | 1.2 L |
| Tube Size | 1-5/8(41) |
| Exhaust / Intake threads | 1.75-20 |
| Pump RPM | 510 RPM |
| Size | 660 x 348 x 476 mm |
| Weight | 215 lb |
| Voltage Rating | 115 V |
| Frequency Rating | 60 Hz |
| Includes | 2 qts DuoSeal vacuum pump oil |
| Phase Type | Single |
