These hot plates are designed to be the easiest to use and most accurate fully featured hot plates in the world. Temperature measurement of a solution is accurate to 1% over the entire temperature range using a 100 ohm platinum RTD sensor and measurement system.Calibration of temperature is electronic and stored in memory. The calibration is set at the factory but can be done easily in the field using the probe calibration kit accessory.The chassis on all models are cast aluminum designed to keep spills and heat out of the electronics. They are coated with chemically resistant epoxy based paint for durability.
Product Type | Hot Plate |
---|---|
Top Size | 20.3 x 20.3 cm |
Top Surface Material | Ceramic |
Operating Temperature Range | 0 to 450 °C |
Readability | 1 °C |
Temperature Control Type | PID |
Temperature Accuracy | ±1 % |
Temperature Stability | 1 °C |
Power | 600 W |
Voltage Rating | 115 V ac, 50/60 Hz |
Fused (Yes/No) | Yes |
Detachable Line Cord (Yes/No) | Yes |
Cord Length | 6 ft;1.8 m |
Platform Material | Cast Aluminum |
I/O Port Type | RS232 |
Control Interface | Digital |
Programmable | Non-Programmable |
Weight | 15 lb;6.8 kg |
Warranty | 12 month |
Standards Met | UL;CSA;CE Compliant |
Dimensions | 9.125 x 4.75 x 15.75 in;232 x 121 x 400 mm |
Platinum RTD | 100 ohm at Zero in Plate |
